Code 61 - 62 Clamps Poster

Compare two-bolt low-pressure and ISO four-bolt flange clamps with O-ring sizes, torque values, and pressure ratings.
*
$0.00

Excerpt From Fluid Power Reference Handbook

This poster provides a detailed comparison of Code 61 and Code 62 hydraulic flange systems, including split and one-piece clamp styles. With labeled technical diagrams and complete dimensional data tables, it helps users understand the differences in flange size, screw length, pressure ratings, and assembly structure. Ideal for fluid power technicians and engineers, this reference supports safe, accurate system design and installation.
